GZF80

The Relpol GZF80 is plug-in sockets for relays: RM84, RM85, RM85 inrush, RM85 105 °C sensitive, RM87L, RM87L sensitive,RM87P, RM87P sensitive. Screw terminals. Max. tightening moment for the terminal: 0,5 Nm. 35 mm rail mount acc. to PN-EN 60715 or on panel mounting 67,2 x 15,5 x 36,5 mm. Two poles, 5 mm pinout. Rated load 10 A, 250 V AC.

For installation planning, GZF80 is intended to work with relays: RM84, RM85, RM85 inrush, RM85 105 °C sensitive, RM87L, RM87L sensitive,RM87P, RM87P sensitive. Screw terminals. Max. tightening moment for the terminal: 0,5 Nm. 35 mm rail mount acc. to PN-EN 60715 or on panel mounting 67,2 x 15,5 x 36,5 mm. Two poles, 5 mm pinout. Rated load 10 A, 250 V AC. This is a model-specific connection or mounting component, so compatibility with the stated Relpol relay family should be confirmed before ordering.

View the Relpol technical datasheet for GZF80
