RSP-EH22/100-960-31
Excl. VAT
RSP-EH22/100-960-31
- Product SKU: 2617378
R 7,010.40
The Relpol RSP-EH22/100-960-31 is surge arresters for high-voltage applications, rated voltage 690 V AC. Plug-in design, class I+II (T1+T2). Peak current Iimp 22kA 10/350, max. discharge current Imax 100kA, rated discharge current 25 kA. For three-phase 3+1 systems, four poles. VT technology Uc 960VAC. Limiters with potential-free contact for remote fault signalling. Width 36 mm per pole.
The protection capability of RSP-EH22/100-960-31 is defined by the surge-current, operating-voltage, pole and class/type values stated above. Those exact ratings should be matched to the protected AC installation and its required lightning/surge protection level.
