RSP-EH25/100-275/10
Rated 3.5/5 based on 11 customer reviews

RSP-EH25/100-275/10

  • Product SKU: 2617366
R 1,509.17
Excl. VAT
Hurry! only 0 left in stock!

The Relpol RSP-EH25/100-275/10 is surge arresters for high-voltage applications, rated voltage 230 V AC. Plug-in design, class I+II (T1+T2). Peak current Iimp 25kA 10/350, max. discharge current Imax 100kA, rated discharge current 25kA. For single-phase networks, single-pole VT technology Uc 275Vac, with potential-free contact for remote fault signalling. Width 36 mm per pole.

The protection capability of RSP-EH25/100-275/10 is defined by the surge-current, operating-voltage, pole and class/type values stated above. Those exact ratings should be matched to the protected AC installation and its required lightning/surge protection level.

View the Relpol technical datasheet for RSP-EH25/100-275/10
