RSP-T1T2-DC 6.25/3P
Rated 3.5/5 based on 11 customer reviews

RSP-T1T2-DC 6.25/3P

  • Product SKU: 2617145
R 436.82
Excl. VAT
Hurry! only 0 left in stock!

The Relpol RSP-T1T2-DC 6.25/3P is surge arrester for DC installations, type T1+T2, number of poles 3. Peak current Iimp: 6.25 kA (10/350), total current Itotal: 12.5 (10/350), rated discharge current In: 20 kA (8/20), maximum discharge current Imax: 50 kA, Uc: Maximum continuous operating voltage 1000 VDC.

The protection capability of RSP-T1T2-DC 6.25/3P is defined by the surge-current, operating-voltage, pole and class/type values stated above. Those exact ratings should be matched to the protected AC installation and its required lightning/surge protection level.

View the Relpol technical datasheet for RSP-T1T2-DC 6.25/3P
