RSP-T2T3-AC/3P
Rated 3.5/5 based on 11 customer reviews

RSP-T2T3-AC/3P

  • Product SKU: 2617139
R 211.23
Excl. VAT
Hurry! only 0 left in stock!

The Relpol RSP-T2T3-AC/3P is surge arrester for AC installations, type T2,+T3, number of poles 3. Rated discharge current In: 10kA (8/20), maximum discharge current Imax: 20kA. Maximum continuous operating voltage Uc: 275-385V. Protection level ≤1.5kV, response time: ≤ 25ns.

The protection capability of RSP-T2T3-AC/3P is defined by the surge-current, operating-voltage, pole and class/type values stated above. Those exact ratings should be matched to the protected AC installation and its required lightning/surge protection level.

View the Relpol technical datasheet for RSP-T2T3-AC/3P
